Automatic Multi Head Rotary Crown Capping Machine

Product Description

N.K Industries, based in Ahmedabad, Gujarat, India, specializes in the production, supply, and export of Automatic Crown Capping Machines. Their product line features several models, including 4-head, 6-head, and 8-head Crown Capping Machines, enabling customers to choose a model that meets their specific output needs. With an impressive output speed of 30 to 100 bottles per minute, these machines are designed to improve efficiency in production lines across various industries.



The Automatic Multi Head Rotary Crown Capping Machines are designed for optimal performance with minimal human intervention, making them perfect for use in distilleries, breweries, cosmetics, toiletries, wine, and beverage sectors. These machines employ a shut pick-up mechanism that ensures crown caps are placed directly onto bottle openings, thereby streamlining the capping process and boosting overall productivity.



Safety is a top priority in the design of these machines, which incorporate advanced safety features such as safety clutches in the star wheel system and feed worm, a "No Bottle No Cap" system, and an automatic cap feeder on/off mechanism. Furthermore, the machines can be fitted with toughened glass or acrylic safety cabinets for added protection. Their adaptability allows them to handle various bottle shapes, including round and square, with minimal adjustments needed.

  • Salient Feature
  • Technical Specification
  • Add On Feature
  • Applicable Industries
  • Compact And Modular Design: The Machine's Compact Size And Modular System Ensure Efficient Space Utilization And Easy Integration Into Existing Production Lines.
  • High-Quality Construction: Parts In Contact With Bottles And Crown Caps Are Made From AISI 304 Stainless Steel, Ensuring Durability And Hygiene.
  • Synchronization: A Single Motor Synchronizes The Conveyor, Star Wheels, And Platform Turret For Smooth Operation.
  • Safety Clutch Devices: Special Safety Clutches Are Integrated Into The In-feed And Out-feed Star Wheel Systems, Halting The Machine If A Vial Is Overturned.
  • Background Suppression Sensor: This Sensor Automatically Stops The Machine If There Are No Crown Caps In The Delivery Chute.
  • No Bottle – No Crown Cap System: Prevents Capping If No Bottle Is Present.
  • Single Cam System: Controls Head Height And Cap Pick-off Assembly For Precise Operation.
  • Jaw-Type Head: Designed For Torque Adjustment, Ensuring Correct Cap Application Without Damaging The Cap Threads.
  • Cap Feeding: Utilizes A Vibrator Feeder System For Efficient Cap Storage And Sorting.
  • Fast Format Changeover: Custom-designed Parts Facilitate Quick Adjustments For Different Container Sizes.
  • Anti-Jamming Design: A Uniquely Designed Position System Prevents Cap Jams.
  • Precise Counting: A 6-digit Counter Helps In Managing Production Processes.
  • Emergency Safety: Outfitted With An Emergency Stop Button For Enhanced Safety.
  • CE Certified Components: All Electrical And External Components Meet CE Certification Standards.

Machine Name

4 head Crown capping machine -Shute pick up

6 head Crown capping machine -Shute pick up

8 head Crown capping machine -Shute pick up

Model

NKCC-150

NKCC-250

NKCC-350

Direction

Left to Right

Left to Right

Left to Right

Production rate

Up to 40 Bottle per minute for 100 ml bottle

Up to 60 Bottle per minute for 100 ml bottle

Up to 80 Bottle per minute for 100 ml bottle

Electrical supply

1 HP for Main Drive
0.25 HP for Vibrator Unit

1 HP for Main Drive
0.25 HP for Vibrator Unit t

2 HP for Main Drive
0.50 HP for Vibrator Unit

No of Crown Capping Head

4 head

6 Head

8 Head

Power requirement

440 V ,3 Phase (4 Wire System ) 50 HZ

440 V ,3 Phase (4 Wire System ) 50 HZ

440 V ,3 Phase (4 Wire System ) 50 HZ

Height of Conveyor

Adjustable from 800 to 850 mm

Adjustable from 800 to 850 mm

Adjustable from 800 to 850 mm

Bottle dia

22 mm to 100 mm max

22 mm to 100 mm max

22 mm to 100 mm max

Bottle height

55 mm to 250 mm max

55 mm to 250 mm max

55 mm to 250 mm max

Crown cap dia

22 mm to 60 mm dia cap
(with the help of change part)

22 mm to 60 mm dia cap
(with the help of change part)

22 mm to 60 mm dia cap
(with the help of change part)

Dimension
(L X W X H) mm

1530 x 815 x 1900

1830 x 812 x 1900

2130 X 915 x 1900

  • PLC-HMI Interface: For Advanced Control And Monitoring.
  • Automatic Head Up And Down System: Enhances Operational Efficiency.
  • Safety Cabinet Options: Available With Toughened Glass, Polycarbonate, Or Acrylic Safety Cabinets For Added Protection.
  • Distilleries & Breweries
  • Cosmetics & Toiletries
  • Lube & Edible Oil
  • Food & Ancillaries
  • Beer And Wine Industries

Why Choose N.K. Industries For Your Crown Capping Machine Requirements?

N.K. Industries Stands Out For Its Commitment To Quality And Innovation. Our Automatic Multi-Head Rotary Crown Capping Machines Are Engineered To Deliver Exceptional Performance With Minimal Maintenance. We Provide Comprehensive Solutions Tailored To Your Specific Needs, Ensuring High Efficiency And Reliability In Your Production Process. Choose N.K. Industries For Cutting-edge Technology, Unmatched Durability, And A Partner Dedicated To Your Success.
