Automatic Single Head Lubricant Oil Bottle Capping Machine Manufacturer

Product Description

N.K Industries, a renowned name in the manufacturing sector based in Ahmedabad, India, is proud to present the Automatic Single Head Lubricant Oil Bottle Capping Machine Model NKSC-60L. Designed to cater to the specific needs of the lube and edible oil industries, this machine is a testament to our commitment to delivering cutting-edge, efficient, and reliable packaging solutions.

The Model NKSC-60L is engineered to offer a seamless and precise capping process, ensuring that your lubricant oil bottles are securely sealed, maintaining the integrity of your products. The machine is powered by a single motor that synchronizes the conveyor, star wheels, and platform turret, offering a modest yet efficient output of up to 30 bottles per minute for 500 ml lubricant bottles.

This model is versatile, capable of handling various container shapes, including round, square, and triangular bottles, with minimal format part changes for caps and bottles. The machine’s design incorporates several advanced features, such as the "No Bottle – No Cap System" and an "Automatic Cap Feeder On/Off System," making it an essential addition to your production line.

Salient Feature
Technical Specification
Add On Feature
Applicable Industries

Compact & Adaptable Unit: The Machine Is Designed To Meet GMP Standards, Ensuring That It Is Compact, Efficient, And Adaptable To Various Production Environments. This Compliance With Good Manufacturing Practices Makes It An Ideal Choice For Companies That Prioritize Quality And Safety In Their Operations.
AISI 304 Contact Parts: All Parts Of The Machine That Come Into Direct Contact With The Bottle Or Screw Cap Are Constructed From AISI 304 Stainless Steel. This Material Is Chosen For Its Durability And Corrosion Resistance, Ensuring The Longevity Of The Machine And The Safety Of The Products.
Single Motor Synchronization: A Single Motor Synchronizes The Conveyor, Star Wheels, And Platform Turret, Reducing The Machine’s Complexity, Making Maintenance Straightforward, And Ensuring Consistent Performance.
Safety Clutch Device: The Star Wheel System Is Equipped With A Safety Clutch Device, Which Stops The Machine Automatically If A Vial Is Overturned, Preventing Damage And Ensuring Operator Safety.
Background Suppression Sensor: This Sensor Stops The Machine Automatically If No Screw Cap Is Detected In The Delivery Chute, Reducing The Risk Of Incomplete Or Faulty Capping, Thereby Enhancing Operational Efficiency.
No Bottle – No Cap System: This Feature Ensures That Caps Are Only Applied When A Bottle Is Present, Preventing Wastage Of Caps And Optimizing Production Efficiency.
Jaw Type Head For Torque Adjustment: The Machine Includes A Specially Designed Jaw-type Head That Allows For Precise Torque Adjustment. This Ensures That The Cap Is Applied Correctly, Preventing Damage To The Cap’s Threads And Avoiding Complaints About Loose Capping.
Versatile Cap Feeding Systems: The Machine Can Be Integrated With Various Cap Feeding Systems, Including A Vibrator Feeder System, Mechanical Orientator System, Or Waterfall Type Elevator, Depending On Your Production Requirements.
Fast Format Changeover: The Design Allows For Quick And Easy Format Changeovers From One Container Size To Another, Minimizing Downtime And Maximizing Productivity.
Cap Jam Prevention System: A Distinct Positioning System Prevents Caps From Becoming Jammed During The Capping Process, Ensuring Smooth And Uninterrupted Operation.
Precise Counting Arrangement: The Machine Is Equipped With A Precise Counting System That Helps Manage Production By Providing Accurate Counts Of Capped Bottles, Essential For Monitoring Efficiency And Meeting Production Targets.
Safety Features: The Machine Includes An Emergency Stop Button For Safety, And All Electrical And Mechanical Components Are CE Certified, Ensuring Compliance With International Safety Standards.

Direction	Left To Right.
Type Of Capping	Screw Capping
Cap Pick On Container	Shut Pick Up
Electrical Supply	1.00 HP For Main Drive
Output	30 Bottle / Minute For 500 Ml Lubricant Oil Can
No Of Sealing Head	Single
Power Requirement	230 Volts, 1 Phase 50 Hz.
Height Of Conveyor	Adjustable From 800 To 850 MM
Dimensions	1530 MM (L) X 850 MM (W) X 1900 MM (H)
Net Weight	550 KGS (Approx.)
Gross Weight	740 KGS (Approx.)
Container Diameter	22 Mm To 100 Mm
Height	15 Mm To 100 Mm
Screw Caps	Diameter: 22 Mm To 56 Mm Height : 15 Mm To 18.3 Mm

PLC - HMI Interface: The Addition Of A PLC With An HMI Interface Allows For Advanced Control And Monitoring, Providing A User-friendly Platform For Adjusting Machine Settings, Monitoring Performance, And Troubleshooting.
Waterfall Type Cap Feeder Elevator: This Optional Feature Provides Mass Storage Of Screw Caps, Ensuring A Continuous Supply During Production And Reducing The Need For Frequent Refills.
Automatic Head Up And Down System: The Machine Can Be Equipped With An Automatic Head Adjustment System That Raises Or Lowers The Capping Head To Accommodate Different Bottle Sizes, Enhancing The Machine’s Versatility.
Toughened Glass Or Acrylic Safety Cabinet: For Added Protection And Cleanliness, A Safety Cabinet Made Of Toughened Glass Or Acrylic Can Be Installed, Allowing A Clear View Of The Capping Process While Maintaining A Controlled Environment.

The Automatic Single Head Lubricant Oil Bottle Capping Machine Model NKSC-60L is Ideal For Use In The Following Industries:

Lube Oil Industry: This Machine Is Perfect For Sealing Lubricant Oil Bottles, Ensuring Product Integrity During Transportation And Storage.
Edible Oil Industry: The Machine Is Also Suitable For Capping Edible Oil Bottles, Providing A Reliable Seal That Preserves The Quality And Freshness Of The Oil.

Why Choose N.K Industries For Your Lubricant Oil Bottle Capping Machine?

Expertise And Experience: N.K Industries Has Years Of Experience In The Manufacturing Industry, With A Deep Understanding Of The Needs Of The Lube And Edible Oil Sectors. Our Machines Are Designed To Meet These Needs With Precision And Reliability.
Customization And Flexibility: We Offer A Range Of Customizable Options And Add-on Features, Allowing You To Tailor The Machine To Your Specific Production Requirements.
Quality And Durability: Our Machines Are Built With High-quality Materials Like AISI 304 Stainless Steel For Contact Parts And CE-certified Components For Electrical Systems, Ensuring Long-lasting Performance.
Global Reach And Support: We Serve Clients Worldwide, Providing Comprehensive Support To Ensure Your Machine Operates At Its Best, No Matter Your Location.
Cost-Effective Solutions: Designed To Maximize Efficiency And Reduce Operational Costs, Our Capping Machines Offer A Cost-effective Solution That Enhances Your Production Line’s Profitability.
Compliance And Safety: All Our Machines Comply With GMP Standards And Feature Advanced Safety Mechanisms, Ensuring They Meet The Stringent Requirements Of The Lube And Edible Oil Industries.

The Automatic Single Head Lubricant Oil Bottle Capping Machine Model NKSC-60L from N.K Industries Is A Highly Versatile, Efficient, And Reliable Solution For The Lube And Edible Oil Industries. With Its Advanced Features, Customizable Options, And Robust Design, This Machine Is An Excellent Investment For Achieving Your Production Goals.
