N.K Industries: Leading Manufacturer of Automatic Vial Sticker Labeling Machine

Product Description

The Automatic Vial Sticker Labeling Machine by N.K Industries is engineered for precise and efficient full or partial wrap-around labeling of vials and bottles in the pharmaceutical sector. This versatile machine accommodates a wide range of vial sizes, from 5 ml to 1000 ml, making it suitable for various production needs.

Designed with cutting-edge technology, the machine features a highly refined, servo-controlled label dispensing system, ensuring exceptional accuracy in label and container sensing. The advanced background suppression photoelectric sensor enhances container detection, guaranteeing seamless operation.

One of the standout features of this machine is its "No Change Parts" capability, allowing it to handle different container diameters without the need for additional parts or tools. This tool-less adjustment significantly reduces downtime, making it a highly efficient solution for your labeling requirements. N.K Industries offers multiple models of the Automatic Vial Sticker Labeling Machine, with some capable of labeling up to 300 vials per minute, depending on the vial diameter and label size.

The machine also includes a single-point synchronized speed control system and an automatic label length detection system as standard features, further enhancing its performance and reliability.

Salient Feature
Technical Specification
Add On Feature
Applicable Industries

Key Features of the Automatic Vial Sticker Labeling Machine

Compact Design & cGMP Compliance: A sleek and compact design that adheres to current Good Manufacturing Practices (cGMP), ensuring quality and safety.
Sturdy Construction: Built with AISI 304 stainless steel, ensuring durability and longevity.
Precision Label Applicator: Superior slider label applicator meticulously designed for optimal label alignment both vertically and horizontally.
Advanced Reel Mechanism: Specially designed for easy roll placement, minimizing variations during roll release.
No Change Parts Required: Seamless adaptation to different container sizes without the need for additional parts.
Tool-less Guide Rails: Easy and quick adjustment of guide rails for different container sizes, reducing setup time.
Efficient Wrap-Around Mechanism: Ensures secure and accurate label application on the container.
Durable Conveyor System: Equipped with a Delrin belt for smooth and reliable container transport.
No Vial - No Label Feature: Ensures no wastage by preventing labels from being applied when there is no vial.
Automatic Label Length Detection: Automatically detects label length, ensuring consistent application.
Accurate Label Dispensing: Precision-engineered for consistent and accurate label placement.
Non-Proprietary Electronics: Utilizes 100% non-proprietary, CE-certified electronics, making maintenance hassle-free.
Virtually Maintenance-Free: Designed for long-term use with minimal maintenance requirements.
Online Batch Coding Integration: Compatible with various online batch coding systems, including ink coder, cassette coder, hot foil coder, and thermal inkjet printer.

MODEL	NKSAL-120V	NKSAL-240V
Machine Operating Direction	Left to Right	Left to Right
Speed	Up to 120 Vial per minute.	Up to 240 Vial per minute.
Type of Labelling	· Vial Labeling Machine	· Vial Labeling Machine
Label Height	10 mm to 160 mm	10 mm to 160 mm
Label Length	12 mm to Unlimited	12 mm to Unlimited
Gap between two labels	Min. 5 mm	Min. 5 mm
Label Roll Dia.	300 mm Max. Ø	300 mm Max. Ø
Label Core Dia.	75 mm to 76 mm Ø	75 mm to 76 mm Ø
Vial Sizes	5 ml to 1000 ml	5 ml to 1000 ml
Power Consumption	1.5 KW	2 KW
Electrical Connection	230 Volts, Single Phase, 50 Hz	230 Volts, Single Phase, 50 Hz
Height of Conveyor	Adjustable from 800 to 850 mm	Adjustable from 800 to 850 mm
Dimension	1830 mm (L) x 950 mm (W) x 1380 mm (H)	2130 mm (L) x 1000 mm (W) x 1380 mm (H)
Weight	250 Kgs (Approx.)	300 Kgs (Approx.)
Gross Weight	400 Kgs (Approx.)	500 Kgs (Approx.)

Label Roll Empty Alarm: Automatically stops the machine and triggers an alarm when the label roll is empty.
Missing Label Detection: Stops the machine and sounds an alarm if a label is missing in the roll.
Special Transparent Film Label Sensor: Detects transparent labels without sensing marks.
Safety Cabinet: Toughened glass or acrylic safety cabinet for enhanced operator protection.
Tower Light Indicator: Displays machine status and operation.
Missing Label Detection on Products: Special sensing system to ensure no labels are missed on products.
Vision System Integration: For barcode verification, presence or absence of coding, pharma code checking, Optical Character Recognition (OCR), and Optical Character Verification (OCV).
Pneumatic Product Rejection: Online pneumatically operated system for rejecting defective products.
Transparent Label Sensor: Specifically designed for detecting transparent labels.

Pharmaceuticals

Why Choose N.K Industries for Your Vial Sticker Labeling Machine Needs?

N.K Industries stands as a leader in the manufacturing of industrial machinery, particularly in the pharmaceutical sector. Our machines are meticulously designed to meet the highest industry standards, ensuring reliability, efficiency, and longevity. With a commitment to continuous innovation and customer satisfaction, N.K Industries offers not just a machine, but a complete solution tailored to your specific needs.

Notes:

N.K Industries reserves the right to make technical enhancements and modifications to the machine.
All illustrations and dimensions are provided for informational purposes only.
