Innovative Wine Bottle Capping Machines By N.K Industries

Product Description

Located in Ahmedabad, India, N.K. Industries stands as a leading manufacturer, supplier, and exporter of top-quality, fully automatic wine bottle capping machines. Renowned for their innovation and excellence in the packaging industry, N.K. Industries introduces a state-of-the-art Automatic Wine Bottle Capping Machine that is designed to meet the rigorous demands of the wine and beverage industries.

This advanced machine is equipped with eight heads and is compatible with Stelvin closures and long aluminum wine caps. Built with precision and efficiency in mind, it delivers an impressive output of 120 to 150 bottles per minute, making it an ideal choice for high-volume production lines. The standout feature of this model is its star wheel-type cap feeder orientator, which ensures high output and seamless operation.

Salient Feature
Technical Specification
Add On Feature
Applicable Industries

N.K. Industries’ Automatic Wine Bottle Capping Machine Is Engineered To Provide Superior Performance, Durability, And Ease Of Use. Here Are Some Of The Key Features That Set This Machine Apart:

Robust, Sturdy Construction: The Machine Is Built With A Robust And Sturdy Construction, Ensuring Longevity And Reliable Performance Even In Demanding Production Environments. The Main Body Of The Machine Is Made From AISI 304 Stainless Steel, Offering Resistance To Corrosion And Easy Maintenance, Making It An Ideal Choice For Food And Beverage Applications.
Modular System Design: The Modular Design Of The Machine Allows For Easy Integration Into Existing Production Lines. This Flexibility Ensures That The Machine Can Be Adapted To Various Production Needs, Whether It’s A New Installation Or An Upgrade To An Existing System.
High-Quality Nylon Bottle Travelling Parts: To Ensure Long-lasting Performance, The Bottle Traveling Parts Of The Machine Are Made From High-quality Nylon Material. This Choice Of Material Not Only Extends The Life Of The Components But Also Ensures Smooth And Consistent Operation, Reducing Wear And Tear.
Synchronized Conveyor, Star Wheels, And Platform Turret: The Machine Features A Single Motor That Synchronizes The Conveyor, Star Wheels, And Platform Turret. This Synchronization Ensures Precise And Coordinated Movements, Leading To A More Efficient Capping Process And Reduced Risk Of Errors.
Special Safety Clutch Device: Safety Is A Top Priority In The Design Of This Machine. A Special Safety Clutch Device Is Integrated Into The In-feed And Out-feed Star Wheel System. This Device Automatically Stops The Machine In The Event Of A Bottle Overturn, Preventing Damage To The Machine And Ensuring Operator Safety.
No Bottle – No Cap System: To Enhance Efficiency And Reduce Wastage, The Machine Is Equipped With A No Bottle – No Cap System. This Feature Ensures That The Capping Operation Only Occurs When A Bottle Is Present, Saving On Cap Usage And Preventing Potential Mishaps.
Adjustable Sealing Pressure: The Machine Allows For Easy Control And Adjustment Of Sealing Pressure To Suit Different Sizes Of Stelvin Caps And Aluminum Long Caps. This Feature Ensures A Perfect Seal For Every Bottle, Regardless Of The Cap Size, Enhancing Product Quality And Shelf Life.
Star Wheel Type Cap Feeder Orientator: One Of The Most Innovative Features Of This Machine Is The Star Wheel-type Cap Feeder Orientator. This System Ensures High-speed And Precise Cap Feeding, Significantly Boosting The Machine’s Overall Output. Additionally, It Can Be Easily Connected To A Waterfall-type Cap Feeder Elevator For Continuous Cap Supply.
Maintenance-Free Worm Gearbox And Gear Motor: The Machine Is Outfitted With A Superior Maintenance-free Worm Gearbox And Gear Motor. This Design Minimizes The Need For Regular Maintenance, Reducing Downtime And Operating Costs While Ensuring Smooth And Reliable Performance.
6-Digit Precise Counting Arrangement: For Accurate Production Management, The Machine Is Equipped With A 6-digit Precise Counting Arrangement. This Feature Allows Operators To Monitor Production Output With Precision, Facilitating Better Planning And Inventory Management.
Emergency Button For Safety: To Further Ensure Safety, The Machine Is Outfitted With An Emergency Button. This Allows Operators To Quickly Stop The Machine In Case Of Any Issues, Preventing Accidents And Protecting Both Personnel And Equipment.
CE Certified Electrical Components: All Electrical Components And Brought-out Items Used In The Machine Are CE Certified, Ensuring Compliance With International Safety And Quality Standards. This Certification Provides Peace Of Mind That The Machine Is Safe To Operate And Built To The Highest Standards.

Model	WINOCAPTIC -120
Direction	Left To Right
Production Rate	Up To 120 Bottle Per Minute
Electrical Supply	2 HP For Main Drive 0.50 HP For Star Wheel Based Orientation Unit
Auto Cap Pick Up Ratio	≥99.7%
Qualified Capping Ratio	≥99.5%
Bottle Breakage Ratio	≤0.5%
No Of Sealing Head	8 Head
Wine Bottle Diameter (mm)	50 MM To 100 MM MAX.
Wine Bottle Height (mm)	100 MM To 320 MM MAXIMUM.
Wine Long Cap Specification	· 25/29 Mm, 25/35 Mm, 25/45 Mm · 28/22 Mm, 28/38 Mm, 28/44 Mm · 30/35 Mm, 30/44 Mm, 30/60 Mm · 31.5 /60 Mm , 31.5/44 Mm
Power Requirement	440 V ,3 Phase (4 Wire System ) 50 HZ
Height Of Conveyor	Adjustable From 800 To 850 Mm
Dimension (L X W X H) Mm	2130 X 915 X 1900

To Further Enhance The Functionality And User Experience, The Automatic Wine Bottle Capping Machine Can Be Equipped With Several Add-on Features:

PLC-HMI Interface With Audit Trail Facility: This Feature Provides Advanced Control And Monitoring Capabilities, Allowing For Better Process Management And Traceability.
Waterfall Type Cap Feeder Elevator: Ensures Continuous Cap Supply To The Star Wheel Feeder, Reducing Manual Intervention And Increasing Efficiency.
Automatic Head Up And Down System: Facilitates Easy Adjustment Of Capping Heads To Accommodate Different Bottle Heights.
Toughened Glass Or Acrylic Safety Cabinet: Offers Additional Protection For Operators And The Machine, While Maintaining Visibility And Access.

The Automatic Wine Bottle Capping Machine Is Particularly Well-suited For The Following Industries:

Beverages: Ideal For Capping Bottles In The Beverage Industry, Ensuring Secure Seals For A Wide Range Of Drinks.
Wine: Specifically Designed To Meet The Needs Of The Wine Industry, Providing Reliable And Efficient Capping Solutions.
Distilleries: Suitable For Use In Distilleries, Where Secure Sealing Of Bottles Is Crucial For Product Integrity.

Why Choose N.K. Industries For Your Automatic Wine Bottle Capping Machine Needs?

When It Comes To Choosing The Right Capping Machine For Your Production Line, N.K. Industries Offers Several Compelling Reasons To Trust Us With Your Requirements:

Unmatched Expertise: With Years Of Experience In The Packaging Machinery Industry, We Understand The Specific Needs Of The Wine And Beverage Sectors, Ensuring That Our Machines Meet And Exceed Industry Standards.
Innovative Technology: Our Machines Are Built With The Latest Technology, Offering Advanced Features That Enhance Efficiency, Reliability, And Ease Of Use.
Custom Solutions: We Provide Tailored Solutions To Meet The Unique Needs Of Your Production Line, Ensuring That Our Machines Integrate Seamlessly With Your Operations.
Global Reach: As A Trusted Exporter, Our Machines Are Used By Leading Companies Around The World, A Testament To Our Commitment To Quality And Customer Satisfaction.
Comprehensive Support: From Initial Consultation To After-sales Service, We Are Dedicated To Providing Exceptional Support And Ensuring That Our Machines Deliver Optimal Performance Throughout Their Lifecycle.

N.K. Industries Is Your Partner In Achieving Excellence In Packaging, Offering State-of-the-art Machinery That Drives Productivity And Ensures The Highest Quality Standards. Trust Us To Deliver The Solutions You Need To Succeed In Today’s Competitive Market.
